Heavy Duty Wear Resistance Plate Chain Type Steel Conveyor

A. Extensive Application of Steel Beam Plate Chain type Conveyor:

1. Task: This hydraulic drive Chain Conveyor sending workpieces among different work stations in a production line. The workpieces are those large and heavy steel structure Beams and steel plates, which are very difficult/ dangerous/ labor consuming if transported by operators;

2. Work Station: In steel structure facilities, especially H Beam Production Line, steel structure Beams are necessary to be transferred among parallel stations. For example, between the 2 sets of H Beam Submerged Arc Welding Machines.

B. Structure and Performance of Steel Beam Plate Chain Conveyor:

1. Structure: As can be checked from the attached photo, the hydraulic drive Steel Chain type Conveyor has the mechanical main body of horizontal supporting rack, with a row of plate link chain running in revolving circulation inside the equipment;

2. Operation Manner in Plate Chain type Conveyor:

1) 2 Sets of Rack Work Together: One set of such structure BOX H Beam Steel Chain Conveyor has 2 sets of the above mentioned supporting racks operating in pair, for holding and conveying the workpiece forward;

2) Remote Pendant: To avoid accidental happens such as sudden falling down of heavy steel workpieces, which may smash onto operator, the operation of this equipment is by means of hand held remote pedant;

3. Advantages of Hydraulic Drive Steel Chain type Conveyor:

1) The plate chain link of this equipment has high intensity, which is durable and wear resistance;

2) The entire set of automatic hydraulic plate chain conveyor for steel structure has stable performance and good adaptability, which is high effectively and easy to operate.

C. Operating Steps in Hydraulic Drive Structure BOX H Beam Steel Chain Conveyor:

1. Step 1, Taking on Workpieces: During work, first the 2 sets of supporting racks are descended down to its bottom position, and take on the workpiece from the first set of production line machine;

2. Step 2, Rising on Workpieces: Then, under the action of hydraulic cylinders which are fit at terminal of the supporting racks, the 2 sets of supporting racks rise up to the same height level of the second set of production line machine;

3. Step 3, Sending forward Workpiece: Meanwhile, driven with motor reducer, the plate link chains of this structure Beam Steel Chain type Conveyor run in full round, conveying the workpiece forward to the target position of the second set of production line machine;

4. Step 4, Workpiece onto the 2^nd Set of Machine: Upon the workpiece reaches at its destination, the 2 sets of supporting racks of this section steel structure Beam Steel Chain Conveyor descends down, and wait for the next round of operation;

D. Technical Parameters of Structure BOX H Beam Steel Chain type Conveyor:
