Hard Rack Form Hydraulic Drive 150 Ton Capacity Large Plate Turnover Machine

A. Usage of Large Plate Turnover Machine:
B. Structure of Heavy duty Plate Overturning Machine:
C. Operating Principle and Working Steps of Heavy duty Large Plate Flipping Machine:
D. Range of Supply of 150 Ton Capacity Heavy duty Large Plate Flipping Machine:
E. Technical Parameters of 150 Ton Capacity Heavy duty Large Plate Turnover Machine:
Availability:
Quantity:

A. Usage of Large Plate Turnover Machine:


1. Function: This hydraulic drive 150 Ton loading and turning capacity Steel Plate Turnover Machine, as its name implies, is used for flipping large and heavy steel plate within the range of 0° ~ 180°. It is kind of steel structure turning over machine;

2. Application: In Bridge Construction sites and Port Machinery facilities, sometimes it is necessary to overturn steel plate within the range of 0° ~ 180°, especially large size thick plate, of which traveling crane can not fulfil the task. Under such condition, the 150 Ton capacity Heavy duty Plate Flipping Machine is a proper choice.


B. Structure of Heavy duty Plate Overturning Machine:


1. This Heavy duty Plate Turnover Machine:


Is composed of:

1) Mechanical main frame--- Groups of hard rack, which are installed inside parallel tunnels inside workshop floor;

2) Hydraulic system --- For driving turning over of hard racks, including hydraulic pump stations;

3) Electrical control system, control cabinet and operating panel;

2. Main frame of the Large Plate Flipping Machine:


Is composed of:

1) 4 pieces of rockshafts --- L shaped arms;

2) Mechanical base frame;

3) Turnover arms

Respectively.


C. Operating Principle and Working Steps of Heavy duty Large Plate Flipping Machine:


1.  Working Steps of Heavy duty Plate Turnover Machine:


1) During operation, workpiece (Large plate) is hoisted onto the 4 sets of the driving arms, and turned over driven with 4 sets of hydraulic cylinders;

2) The 4 sets of idle arms waits at 95° angular position. When the workpiece plate is turned over to idle arms at about 90°, the 4 sets of idle arms take over the workpiece plate and flip it to the horizontal position;

3) In this way, the workpiece plate is turned over 180° with these 4 sets of plate overturning racks successfully;

2. Running Principle of Large Plate Overturning Machine:


1) During work of the machine, the 4 sets of driving arms and 4 sets of idle arms turn over the workpiece simultaneously;

2) The 4 sets of driving arms are driven with hydraulic station;

3) Each pair of the driving and idle arms are laid inside ground pit when the Large Plate Turnover Machine is not in work;

4) The hydraulic oil cylinders are also installed inside the workshop floor pit. During working period of the Large Plate Flipping Machine, the oil cylinders act and push up the driving arms, which in turn rotate and flip the workpiece plate;

3. Electric cables and hydraulic oil pipes of this Heavy duty Plate Turnover Machine are arranged through drag chain, featuring in safe operation, good appearance and consistent delivery;

4. Advantages: The entire set of Large Plate Turnover Machine has compact size and user friendly operation. When not in operation, its groups of driving and follower arms are laid inside workshop pit, removing safety potential risk of tumbling down, and leaving ample space for operation.


D. Range of Supply of 150 Ton Capacity Heavy duty Large Plate Flipping Machine:


Four sets of mechanical frames, each has one set of drive arm and one idle arm respectively;

1) Eight sets of overturning oil cylinder, overturning bearing bed, and hose, electromagnetic valves;

2) One set of 15kW hydraulic pump station;

3) One set of electrical control board and operating pendant


E. Technical Parameters of 150 Ton Capacity Heavy duty Large Plate Turnover Machine:


Large Plate Flipping Angle Range

0° ~ 180°

Max. Loading Capacity of Large Plate

150 Tons

Max. Plate Width for Flipping

4000 mm

Max. Plate Length for Flipping

15000 mm

Max. Plate Thickness for Flipping

150 mm

180° Overturning Time Spent

2.5 min.

Max. Pressure of Hydraulic System

16 MPa
