Background: In this set of Wuxi JACK ASM160 model Angle Steel Straightening Machine of the attached first photo, you can identify that, the transmission chains of the main driving motor are open in the air. It is because this set of machine would be ready for shipment and many assemblies were disassembled and packed. For working at customer site, this set of Angle Iron Straightening Machine will have its transmission chains covered for safety purpose.
1) Straightening Capability: Same as ASM100 and ASM130 models, the ASM160 is a frequently used model of ASM series machine for Angle Iron straightening purpose, because its workpiece size range falls into extensive application in the market: The available maximum cross section size of the Angle Steels to be straightened in this model is 160 x 160 x 12mm;
2) Useful Purpose: Angles Steel (Or, L steel/ Angle Iron) is a kind of section steel with simple cross section shape. It can be used as metal structure members and or factory building. To make these raw materials straightened is a requisite step before construction;
3) For working progress of Wuxi JACK ASM200 model L Steel Straightening Machine, please check the 2nd photo and attached video.
Mechanical main body of the ASM series machine tool, for fulfilling Angle Steel automatic straightening has ingenious design on machine structure, with compact size, please check the attached Photos:
1) High Precision Machining: The vertical movement of top position straightening rollers is guided with its “Roller Carriage” (As shown in the attached 3rd photo), which, together with its “Press Plate”, are went thru precision machining of milling before assembled into the machine main body (As can be seen from the attached pictures, anti-rust oil is applied its surface also), fully guaranteeing on up and down movement of the straightening rollers in high degree of precision;
2) Working Cavity: For these Wuxi JACK ASM series longitudinal Angle Bar Straightening Machine, for each piece of its top straightening rollers, the couple fit of “Roller Carriage” with “Press Plate” make sure the top straightening rollers can only move along vertical direction: Without clearance on horizontal direction of both forward and backward, as well as leftward and rightward, the straightening rollers are not available on moving in these directions (Which means No Drifting). The “Press Plate” also serves as guiderail for vertical movement of the “Roller Carriage” and hence top straightening rollers, which is the No.1 important movement during working of the ASM series Angle Iron Straightening Machine;
Central working cavity being assembled into machine main frame of ASM160 model: (Fig.1)
3) Half Circled Enclosure: Besides, as can be seen from the picture, the 4~5 sets of “Roller Carriage” and “Press Plate” pair in this longitudinal Angle Steel Straightening Machine are designed in the fashion of semi-closed, in this way, straightening process can be observed without difficulty during work, and also be convenient for maintenance and service:
Half enclosed working cavity of ASM100 model: (Fig.2)
4) In summary, mechanical main body of these high velocity (Straightening speed of 6m/ min.) Angle Bar Straightening Machine is of gantry type, which is not only practical and sturdy, but also of good appearance and easy handling;
a) For understanding straightening principle of the machine, please check product section of “Universal ASM200 model machine for automatic high speed Steel Angle traightening”;
b) For straightening roller of the machine, please check product section of “ASM100 model machine, for all purpose automatic straightening on Angle Iron along lengthways direction”;
c) For transmission and control system of the machine, please check product section of “High efficiency machine, for automated straightening on L Steel along length direction”.
Model Technical Parameter | ASM160 Angle Iron Straightening Machine |
Min. Cross Section size of Angle Iron (mm) | 50 ×50× 5 |
Max. Cross Section size of Angle Iron (mm) | 160 ×160×12 |
Max. Length of Angle Iron (mm) | 10,000 |
Angle Iron Straightening Speed (mm/min.) | 6000 (Fixed Speed) |
Straightening Rollers Interval (mm) | 550 |
Input Conveyor Length (m) | 5.8 (Or designated by customer) |
Output Conveyor Length (m) | 5.8 (Or designated by customer) |
